Feature
- Screen size 15", resolution 1024X768
- Built-in speakers
- HDMI, RJ45, USB, Audio
- Screen aspect ratio 4:3
- Specification
| Item | Specification | |
| Panel | Model | G150XTN03.5 |
| Resolution | 1024 X 768 | |
| Size | 15 inch | |
| Display Area(mm) | 304.128(H) x 228.096(V) | |
| Brightness | 350 cd/m2 (Typ) | |
| Contrast | 800:1 | |
| View Angle | 160 | |
| Response Time | 5.7ms Typ | |
| Color | 16.2M / 262K colors | |
| Aspect Ratio | 04:03 | |
| LED Backlight Lifetime | 50,000 Hrs. | |
| Display Orientation | Landscape | |
| Power | Consumption | 10.6W |
| Input | DC 12V | |
| Main board | RK3288 | Rockchip RK3288, ARM Cortex-A17 quad core |
| 32 bit processor, 1.5GHz, Android 8~10 | ||
| IO | HDMI, RJ45, USB, Audio | |
| Others | Speaker | YES |
| Accessory | 12V Adaptor | |
| Item | Specification |
| CPU | Rockchip RK3288, ARM Cortex-A17 quad core 32 bit processor, 1.5GHz |
| GPU | Mail-T764 GPU MP4, quad core GPU Support OpenGL ES1.1/2.0/3.0,OpenVG1.1,OpenCL,DX11, AFBC |
| Memory | DDR3 2G（up to 4G max） |
| Built in memory | eMMC 8GB (16G/32G/64G/128G optional); TF Card extended( for SSD) |
| Network | RJ45/ Ethernet, 1000M supported |
| 2.4G , 5 G WiFi, Wi-Fi 802.11b/g/n protocol | |
| Bluetooth 4.2 | |
| Image rotation | Support 0/90/180/270 degree，270 degree manual rotation，Gravity sensor (optional) |
| Display interface | 1*LVDS（single/dual，6bit/8bit）, support to 7"-108" 1080P |
| 60Hz output, 3.3V/5V/12V power supply option | |
| 1*HDMI 2.0, support 4K 60Hz | |
| Black light | 3.3V/5V/12V supported/optional |
| Audio | 1* speaker output(2*6W 4R THD＜10%) ;1*microphone input |
| Touch display | 1* I2C interface（support multi point PCAP touch）。 |
| Support USB multi point IR touch etc | |
| Camera | 1* MIPI Camera, support 500W/1300W（optional）, 800W-USB （optional） |
| RTC | Real time clock through battery, power on/off |
| USB | 5*USB-2.0 HOST , 1*USB2.0 OTG |
| IR | 1*IR receiver, IR remote |
| LED | 1*Power/ LED(RED),1*System/ LED(BLUE, flashed) |
| Button | 1*home,1*power,1*upgrade |
| Serial port | 3*UART TTL |
| IO | 6*IO , input and output supported |
